Family House

We have created a 3D model of a family house in Ústí nad Labem.

1 100 m2

For more information, scroll

Detailed description

The contract assignment was to create 2D construction documentation (floor plans, building sections, and views) for the family house. Data collection was performed using ground-based laser scanning.

‍

Creation of 3D Model

The whole object was focused using a Trimble X7 laser scanner. At the same time, georeferencing to S-JTSK was carried out using GNSS points. The obtained point clouds were processed and digitised in Autodesk ReCap and Revit, InfraWorks software.

‍

Output Data Format: RVT

Drawing of a family house

Point cloud

3D model

Request a sample of the output data

or contact us directly.

Objectives and Benefits

High precision in object processing
Point cloud validation
No need for additional surveying

‍

Graphic Benefits

High precision object surveying
Determination of the detailed properties and general geometry of the building
Possibility to measure the thickness of the individual elements and type of joints

Technologies used

Trimble X7

The high-speed scanning station is the latest innovative solution in mapping, engineering, and surveying that provides data visualisation directly in the field. Fully integrated 3D scanning functions form its basis. It allows for data to be exported to standard point cloud formats.

Request a sample of output data
